Online Power Frequency Machine UPS Three In And Three Out
If you need, please get our online timely service about Online power frequency machine UPS three in and three out. In addition to the product list below, you can also customize your own unique Online power frequency machine UPS three in and three out according to your specific needs.
Online power frequency machine UPS three in and three out product overview
Online power frequency machine UPS three in and three out（10-120KVA）Series three-phase power frequency UPS is designed for data centers, network computer rooms, intelligent precision equipment (such as measuring devices, industrial automation equipment, etc.) designed high performance sine wave high power uninterruptible power supply. Adopt advanced digital control technology, superior performance of SPWM inverter, intelligent multi-mode battery management technology and other international advanced technology, friendly LCD interface design, so that man-machine communication zero distance; UPS and PC through the RS232 communication port to understand the UPS work history, parameter monitoring, automatic switching, unattended and remote network monitoring functions (through SNMP card), can adapt to the use of advanced network systems, has a good cost performance and user base. Its high reliability provides important power protection for high-power equipment in finance, communications, insurance, transportation, taxation, military, securities, energy, education, government, manufacturing, enterprises and other industries.
Online power frequency machine UPS three in and three out peculiarity
1. High reliability of design concept
2. High reliability
3. Strong environmental adaptability
4. High battery optimization performance
5. Comprehensive and reliable protection
6. Online power frequency machine UPS three in and three out. Humanized man-machine interface
Online power frequency machine UPS three in and three out technical parameter
| Capacity | 10KVA/8KW | 15KVA/12KW | 20KVA/16KW | 30KVA/24KW | 40KVA/32KW | 60KVA/48KW | 80KVA/64KW | 100KVA/80KW | 120KVA/96KW |
| Phase number | Three phase | ||||||||
| Voltage range | 380V±20% | ||||||||
| Frequency range | 45Hz TO 65Hz | ||||||||
| rectifier | Three-phase six-pulse | ||||||||
| Power factor | 0.95(with filter) | ||||||||
| Wave form | Sinusoidal wave | ||||||||
| Peak value ratio | 3:01 | ||||||||
| Rated voltage | 380V/400V/415V selectable | ||||||||
| Transient response | ＜2% | ||||||||
| frequency | 50Hz/60Hz | ||||||||
| Frequency accuracy | ±0.05% (Battery mode) | ||||||||
| Harmonic distortion | Output 0-50%~100% ≤3%, recovery time ≤10ms | ||||||||
| Short-circuit current | Short circuit current 200%0.1S | ||||||||
| Overload capacity | Electric current 110%/125%/150%300min/10min/1min | ||||||||
| Power factor | 0.8 | ||||||||
| Battery type | Maintenance-free sealed lead-acid battery | ||||||||
| Dc voltage | 360V | 384V | 432V | 480V | |||||
