20AH-110V DC Distribution Panel

NICEA 20AH-110V DC Distribution Panel, belonging to the GZDW series of microcomputer-controlled DC panels, is designed for substations, power stations, industrial and mining enterprises, electrified railways and high-rise buildings of different voltage levels, as the operation and control power supply for high-voltage switches, relay protection and automatic devices. The system adopts an integrated design concept, integrating monitoring modules, rectifier modules, insulation monitoring, battery inspection, switch quantity monitoring and step-down modules, etc., showing the characteristics of leading technology, intelligent measurement and control, and convenient operation. It supports communication with the host computer and easily realizes the "four remote" functions. It is an ideal DC power supply solution for unattended environments.

Detailed explanation of functional characteristics

Automatic switching of dual-channel AC input: ensures continuous and stable operation of the system.

Wide voltage input adaptability: suitable for a variety of power grid environments, especially for harsh conditions.

High-frequency switching power supply technology: modular N+1 hot backup design to improve system reliability.

Rectifier module hot plug: supports online maintenance, convenient and efficient operation.

Efficient switch technology: The charging module adopts the latest international technology, with high conversion efficiency and low electromagnetic interference.

Diversified monitoring interface: LCD screen, touch screen and other options are provided, with friendly interface and intuitive operation.

Open communication interface: Easily connect to substation RTU or power plant DCS system.

Intelligent battery management: Real-time monitoring of battery status, with patrol meter, more accurate fault warning.

Flexibility of insulation monitoring: Built-in or external insulation relay/detector to meet various needs.

DC bus insulation monitoring: Real-time monitoring to ensure system safety.

Signal box expansion: Support accident/warning signal alarm function, configured on demand.

Lightning protection and insulation protection: Multiple protection measures to ensure system and personal safety.

Communication interface and protocol: Provide RS232 and RS485 interfaces, support RTU, CDT, MODBUS and other communication protocols.

System debugging and preparation

Before leaving the factory, NICEA 20AH-110V DC Distribution Panel has been fully tested and adjusted. Nevertheless, considering the unforeseen factors that may exist during transportation, a detailed inspection is still required before formal operation. It is recommended to use a resistive load for trial operation first, and then connect the battery and load after confirming that the performance of the charger and the operating voltage of the feeder cabinet meet the standards. The potentiometer in the equipment has been adjusted according to the specifications. Do not move it unless necessary. If adjustment is required, please contact the manufacturer.

Packaging, transportation and storage guide

Professional packaging: Use a fully enclosed packaging box that is moisture-proof, dust-proof, and mechanically damaged, and the battery is packaged separately.

Safe transportation: Avoid severe vibration, impact or inversion to ensure product safety.

Proper storage: The equipment should be stored in a ventilated and dry environment, away from high temperature, dust and metal powder, and take rain, moisture and sun protection measures.

Battery storage: Place in a dry and ventilated environment with a room temperature not exceeding 25°C and a humidity not exceeding 70%. Long-term storage requires regular charging and discharging, and Vaseline protection.

Attached documents

Includes system manual, factory inspection report, system design drawings and product certificate to ensure that users fully understand and use our20AH-110V DC Distribution Panel.

After-sales service and ordering guide

After-sales service commitment:

Under the premise of complying with the rules of storage, use, installation and safe operation, within one year from the date of installation (no more than 15 months from the date of delivery), we will provide commissioning, repair or replacement of parts due to problems caused by manufacturing quality.

Ordering notes:

Clearly define the application scenarios and uses of the equipment.

Provide the equipment name, model, specifications or system parameter requirements.

If there are special use environments or technical requirements, please explain in detail when ordering.

Matters not covered shall be subject to the order contract, and matters not specified in the contract shall refer to the manufacturer's technical documents.
